модель 2007 года
- Модель Rhino 450
- Код модели RHINO 450 (YXR45FW)
Схема подножки и подставки для RHINO 450 (YXR45FW)
Схема
Детали
Номер
Наименование детали
Цена
1
Подножка левая Yamaha art. 5UG-F7411-12-00
По запросу
2
RIVET, BLIND art. 90267-48820-00
По запросу
3
COVER, FOOTRESTThis item has been discontinued and may not be available. Contact us for more information. art. 5UG-F7413-00-00
По запросу
4
SEAL 2This item has been discontinued and may not be available. Contact us for more information. art. 5UG-F8228-01-00
По запросу
5
BOLT, WITH WASHER art. 90119-05001-00
По запросу
6
NUT, SPRING art. 90183-05073-00
По запросу
7
Подножка правая Yamaha Rhino art. 5UG-F7421-12-00
По запросу
8
COVER, DUST art. 5UG-F7286-00-00
По запросу
9
Пистон пластиковый Yamaha art. 90269-06800-00
По запросу
10
BRACKET, PEDAL SUPPORT(replaces 5UG-F2548-00-00) This item has been discontinued and may not be available. Contact us for more information. art. 5UG-F2548-01-00
По запросу
11
Болт с фланцем Yamaha art. 95817-08020-00
от 935 ₽
12
ACCEL PEDAL ASSYThis item has been discontinued and may not be available. Contact us for more information. art. 5UG-F7801-00-00
По запросу
13
WASHER, PLATE art. 90201-15797-00
По запросу
14
CIRCLIP art. 93430-12008-00
По запросу
15
SPRING, TENSION(replaces 90506-20534-00) art. 90506-20009-00
По запросу
16
PEDAL, BRAKEThis item has been discontinued and may not be available. Contact us for more information. art. 5UG-F7200-00-00
По запросу
17
WASHER, PLATE art. 90201-15797-00
По запросу
18
CIRCLIP art. 93430-12008-00
По запросу
19
SPRING, TENSION(replaces 90506-20534-00) art. 90506-20009-00
По запросу
20
Трос газа Yamaha art. 5UG-26311-10-00
По запросу
21
CLAMP art. 90464-20005-00
По запросу
22
CLAMP art. 90464-40825-00
По запросу
23
CLAMP art. 90464-12830-00
По запросу
24
PARKING BRAKE COMP.This item has been discontinued and may not be available. Contact us for more information. art. 5UG-F5970-00-00
По запросу
25
. .SWITCH COMP. art. 5UG-H251S-00-00
По запросу
26
KNOB, PARKING LEVERThis item has been discontinued and may not be available. Contact us for more information. art. 5UG-F5664-00-00
По запросу
27
SCREWThis item has been discontinued and may not be available. Contact us for more information. art. 5UG-F589H-00-00
По запросу
28
Болт с фланцем Yamaha art. 95817-06016-00
от 326 ₽
29
WIRE, BRAKE 1 art. 2P5-26341-00-00
По запросу
30
CLAMP art. 90464-16039-00
По запросу
31
CLAMPThis item has been discontinued and may not be available. Contact us for more information. art. 90461-08802-00
По запросу
32
BOLT, FLANGE art. 90105-06831-00
По запросу
33
CABLE, STARTER 1 art. 2P5-26331-00-00
По запросу
34
NUT(replaces JN6-F6333-10-00) art. JU0-F6333-00-00
По запросу
35
CLAMP art. 90464-16115-00
По запросу
36
CLAMP art. 90464-31827-00
По запросу
37
COVER, HANDLE LEVER 1 art. 5UG-F6372-00-00
По запросу
38
PLATE, SPLASH(replaces 5UG-G5158-00-00) This item has been discontinued and may not be available. Contact us for more information. art. 5UG-G5158-10-00
По запросу
39
Пистон пластиковый Yamaha art. 90269-06800-00
По запросу
40
SCREWThis item has been discontinued and may not be available. Contact us for more information. art. 5UG-F589H-00-00
По запросу
