модель 2005 года
- Модель SV650
- Код модели SV650
Схема сиденье Tail крышка (Sv650sk5) для SV650
Схема
Детали
Номер
Наименование детали
Цена
1
COVER SET, SEAT TAIL, R (YELLOW) art. 45501-16G21-YEC
По запросу
1
COVER SET, SEAT TAIL, R (BLACK) art. 45501-16G21-YAY
По запросу
1
COVER SET, SEAT TAIL, R (RED) Includes Item(s) 2 - 5 art. 45501-16G21-YU7
По запросу
1
COVER SET, SEAT TAIL, R (BLUE) art. 45501-16G21-YC2
По запросу
2
COVER, SEAT TAIL, R (BLUE) art. 45501-16G21-YC2
По запросу
2
COVER, SEAT TAIL, R (YELLOW) art. 45501-16G21-YEC
По запросу
2
COVER, SEAT TAIL, R (BLACK) art. 45511-16G01-YAY
По запросу
2
COVER, SEAT TAIL, R (RED) art. 45511-16G02-YU7
По запросу
3
TAPE, SEAT TAIL COVER FR art. 45516-42F00-000
По запросу
4
TAPE, SEAT TAIL COVER FR NO.2 art. 45517-16G10-000
По запросу
5
TAPE, SEAT TAIL COVER FR NO.3 art. 47161-10D00-000
По запросу
6
COVER SET, SEAT TAIL, L (RED) Includes Item(s) 7 - 10 art. 45502-16G21-YU7
По запросу
6
COVER SET, SEAT TAIL, L (BLACK) art. 45502-16G21-YAY
По запросу
6
COVER SET, SEAT TAIL, L (YELLOW) art. 45502-16G21-YEC
По запросу
6
COVER SET, SEAT TAIL, L (BLUE) art. 45502-16G21-YC2
По запросу
7
COVER, SEAT TAIL, L (RED) art. 45512-16G02-YU7
По запросу
7
COVER, SEAT TAIL, L (BLACK) art. 45512-16G01-YAY
По запросу
7
COVER, SEAT TAIL, L (YELLOW) art. 45512-16G02-YEC
По запросу
7
COVER, SEAT TAIL, L (BLUE) art. 45512-16G02-000
По запросу
8
TAPE, SEAT TAIL COVER FR art. 45516-42F00-000
По запросу
9
TAPE, SEAT TAIL COVER FR NO.2 art. 45517-16G10-000
По запросу
10
TAPE, SEAT TAIL COVER FR NO.3 art. 47161-10D00-000
По запросу
11
SCREW art. 09136-06082-000
По запросу
12
SPACER art. 09180-06286-000
По запросу
13
CUSHION FR art. 09320-10079-000
По запросу
14
CUSHION CTR art. 47115-16G01-000
По запросу
15
CUSHION RR art. 09320-20011-000
По запросу
16
SCREW art. 03241-1512B-000
По запросу
17
NUT art. 09148-05038-000
По запросу
18
COVER, SEAT TAIL, CENTER (RED) Includes Item(s) 19 - 22 art. 45503-16G00-YU7
По запросу
18
COVER, SEAT TAIL, CENTER (BLACK) art. 45503-16G01-YAY
По запросу
18
COVER, SEAT TAIL, CENTER (YELLOW) art. 45503-16G00-YEC
По запросу
18
COVER, SEAT TAIL, CENTER (BLUE) art. 45503-16G01-YC2
По запросу
19
EMBLEM, "SUZUKI" FOR YEC art. 68161-16G00-17U
По запросу
19
EMBLEM, "SUZUKI" FOR YC2,YAY,YU7 art. 68161-16G01-YD8
По запросу
20
CUSHION, SEAT TAIL COVER CTR art. 45518-16G00-000
По запросу
21
TAPE, SEAT TAIL COVER art. 45517-16G00-000
По запросу
22
TAPE art. 45516-42F00-000
По запросу
23
COVER, SEAT TAIL, REAR (BLUE) art. 45514-16G00-YC2
По запросу
23
COVER, SEAT TAIL, REAR (YELLOW) art. 45514-16G00-000
По запросу
23
COVER, SEAT TAIL, REAR (BLACK) art. 45514-16G00-YAY
По запросу
23
COVER, SEAT TAIL, REAR (RED) art. 45514-16G00-YU7
По запросу
24
NUT art. 09148-06018-000
По запросу
25
Клипса Suzuki art. 09409-06314-5PK
от 326 ₽
26
HANDLE, PILLION RIDER (BLUE) art. 46211-16G00-YC2
По запросу
26
HANDLE, PILLION RIDER (YELLOW) art. 46211-16G00-13L
По запросу
26
HANDLE, PILLION RIDER (BLACK) art. 46211-16G00-YAY
По запросу
27
BOLT art. 01551-0840B-000
По запросу
28
WASHER art. 09160-08501-000
По запросу
29
SPACER art. 09180-06271-000
По запросу
30
SCREW art. 09139-06112-000
По запросу
